Accurate Speed measurement using the UltraSonic sensor

Using HCSR04 and basic maths !

IntermediateFull instructions provided5,957
Accurate Speed measurement using the UltraSonic sensor

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
Ultrasonic Sensor - HC-SR04 (Generic)
Ultrasonic Sensor - HC-SR04 (Generic)
×1
Jumper wires (generic)
Jumper wires (generic)
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Code

Speed measurement

C/C++
const int trigPin = 5;
const int echoPin = 6;


long duration;
int FirstDistance=0;
int SecondDistance=0;
double speed=0;
int distance=1;
float Time = 2.0;
float delayedtime = 1000*Time;

void setup()
{
pinMode(trigPin, OUTPUT);
pinMode(echoPin, INPUT);
Serial.begin(9600);
}


void loop()
{
GetSpeed();

}

float GetDistance()
{
// Clears the trigPin
digitalWrite(trigPin, LOW);
delayMicroseconds(2);

// Sets the trigPin on HIGH state for 10 micro seconds
digitalWrite(trigPin, HIGH);
delayMicroseconds(10);
digitalWrite(trigPin, LOW);

// Reads the echoPin, returns the sound wave travel time in microseconds
duration = pulseIn(echoPin, HIGH);

//calculating distance
distance= duration*0.034/2;

// Prints the distance on the Serial Monitor
Serial.print("Distance in cm : ");
Serial.println(distance);

return distance;

}
void GetSpeed(){

   FirstDistance = GetDistance(); //get the first distance

   delay(delayedtime); //waits 2 seconds depending on the time declared above ,, feel free to change the value dependng on the resolution of your sensor

   SecondDistance = GetDistance(); //gets the second distance

   speed = (FirstDistance - SecondDistance)/Time;  // now calculating the difference


//printing the speed on the serial monitor
  Serial.print("the speed (cm/s) is  :  ");
  Serial.println(speed);

}
