Radar or Sonar - Which One Is Correct?

Build your sonar at home!

IntermediateFull instructions provided1,733
Radar or Sonar - Which One Is Correct?

Things used in this project

Hardware components

Ultrasonic Sensor - HC-SR04 (Generic)
Ultrasonic Sensor - HC-SR04 (Generic)
×1
Arduino Nano R3
Arduino Nano R3
×1

Software apps and online services

Arduino IDE
Arduino IDE
Processing
The Processing Foundation Processing

Story

Read more

Schematics


Code

Untitled file

C/C++
#include <Servo.h>.

const int trigPin = 10;
const int echoPin = 11;

long duration;
int distance;
Servo myServo;
void setup() {
  pinMode(trigPin, OUTPUT);
  pinMode(echoPin, INPUT);
  Serial.begin(9600);
  myServo.attach(12);
}
void loop() {

  for(int i=15;i<=165;i++){
  myServo.write(i);
  delay(30);
  distance = calculateDistance();/

  Serial.print(i);
  Serial.print(",");
  Serial.print(distance);
  Serial.print(".");
  }

  for(int i=165;i>15;i--){
  myServo.write(i);
  delay(30);
  distance = calculateDistance();
  Serial.print(i);
  Serial.print(",");
  Serial.print(distance);
  Serial.print(".");
  }
}

int calculateDistance(){

  digitalWrite(trigPin, LOW);
  delayMicroseconds(2);

  digitalWrite(trigPin, HIGH);
  delayMicroseconds(10);
  digitalWrite(trigPin, LOW);
  duration = pulseIn(echoPin, HIGH);

  distance= duration*0.034/2;
  return distance;
}
