#include <linux/module.h>
#include <linux/of_device.h>
#include <linux/of.h>
#include <linux/kernel.h>
#include <linux/gpio/consumer.h>
#include <linux/platform_device.h>
#include <linux/interrupt.h>
#include <linux/ktime.h>
#include <linux/moduleparam.h>

// Encoder pin info and timestamp tracking
static unsigned int irq_number;
static struct gpio_desc *encoder_gpio;
static volatile u64 prev_time_ns;
static volatile u64 curr_time_ns;

// Time between encoder pulses, in ms (used to calculate speed)
static int speed_ms = 0;
module_param(speed_ms, int, 0644);

// === IRQ Handler ===
static irqreturn_t encoder_irq_handler(int irq, void *dev_id) {
    int signal_level = gpiod_get_value(encoder_gpio);
    curr_time_ns = ktime_get_ns();

    unsigned long elapsed_ns = curr_time_ns - prev_time_ns;

    // Update speed if signal is high and debounce threshold passed
    if (signal_level == 1 && elapsed_ns > 1000000) {
        prev_time_ns = curr_time_ns;
        speed_ms = (int)(elapsed_ns / 1000000);  // Convert ns -> ms
        printk(KERN_INFO "encoder_irq_handler: interval = %d ms\n", speed_ms);
    }

    return IRQ_HANDLED;
}

// === Driver Probe ===
// Call when device is initialized
static int encoder_probe(struct platform_device *pdev) {
    struct device *dev = &pdev->dev;

    printk(KERN_INFO "encoder_probe: Initializing...\n");

    // Gets GPIO descriptor from device tree
    encoder_gpio = gpiod_get(dev, "encoder", GPIOD_IN);
    if (IS_ERR(encoder_gpio)) {
        printk(KERN_ERR "encoder_probe: Failed to acquire GPIO\n");
        return PTR_ERR(encoder_gpio);
    }

    gpiod_set_debounce(encoder_gpio, 1000000);  // 1 ms debounce

    // Gets the IRQ number
    irq_number = gpiod_to_irq(encoder_gpio);
    if (request_irq(irq_number, encoder_irq_handler, IRQF_TRIGGER_RISING, "encoder_irq", NULL)) {
        printk(KERN_ERR "encoder_probe: IRQ request failed\n");
        return -1;
    }

    // Time tracking
    prev_time_ns = ktime_get_ns();
    printk(KERN_INFO "encoder_probe: Success\n");
    return 0;
}

// === Driver Remove ===
// Called for when module unloaded
static void encoder_remove(struct platform_device *pdev) {
    free_irq(irq_number, NULL);
    printk(KERN_INFO "encoder_remove: Module unloaded\n");
}

// === Device Tree Match Table ===
// To tell kernel which device tree entries are supported
static const struct of_device_id encoder_of_match[] = {
    { .compatible = "encoder,elec424,youngsters", },
    { }
};
MODULE_DEVICE_TABLE(of, encoder_of_match);

// === Platform Driver ===
// Registers encoder driver with kernel
static struct platform_driver encoder_driver = {
    .probe  = encoder_probe,
    .remove = encoder_remove,
    .driver = {
        .name = "encoder_driver",
        .owner = THIS_MODULE,
        .of_match_table = of_match_ptr(encoder_of_match),
    },
};

module_platform_driver(encoder_driver); // platform driver registered

MODULE_LICENSE("GPL v2");
MODULE_AUTHOR("Joseph's Youngsters");
MODULE_DESCRIPTION("Optical Encoder Driver");
MODULE_ALIAS("platform:encoder_driver");

import time
import cv2
import numpy as np
import math
import sys
import os
import RPi.GPIO as GPIO
import matplotlib.pyplot as plt

# === Team & Setup ===
# Ben Welchman, Junho Kim, Aaron Juarez

GPIO.setmode(GPIO.BCM)

# === GPIO SETUP ===
throttle_pin = 19  # ESC throttle
steer_pin = 21  # servo steering

GPIO.setup(throttle_pin, GPIO.OUT)
GPIO.setup(steer_pin,    GPIO.OUT)

pwm_esc = GPIO.PWM(throttle_pin, 50)
pwm_serv = GPIO.PWM(steer_pin,    50)

pwm_esc.start(7.5)  # neutral throttle
pwm_serv.start(7.5) # straight steering

# === Encoder & Speed PD Settings ===
mods = [m for m in os.listdir("/sys/module") if m.startswith("encoder")]
encoder_path = f"/sys/module/{mods[0]}/parameters/speed_ms"
print("Using encoder_path:", encoder_path)

desired_ms = 15.0  # target interval between pulses
kp, kd = 0.1, 0.045
base_speed = 8.1   # nominal running duty
throttle_min = 7.7   # full stop duty
throttle_max = 8.3   # full forward duty
_prev_err = None
_prev_time = None

# === Steering PD Settings ===
kp_s, kd_s = 0.3, 0.5
zero_turn = 7.5
servo_min = 6.0
servo_max = 9.0

# === Camera Settings (resolution size) ===
frame_w, frame_h = 250, 120
cam_idx = 0

# === Lane‑line EMA ===
ema_alpha = 0.2
prev_left = None
prev_right = None

# === Stop‑sign for Red‑floor ===
RED_THRESHOLD = 750  # pixel threshold for stopping at red light

# === Variables for plotting ===
p_vals = []
d_vals = []
err_vals = []
speed_vals = []
steer_vals = []

def read_encoder():
    try:
        with open(encoder_path, "r") as f:
            return float(f.read().strip())  # read speed in ms
    except Exception as e:
        print(f"[read_encoder] ERROR: {e}", file=sys.stderr)
        return None

def manage_speed():
    """
    Adjust throttle duty cycle using PD control of encoder interval.
    """
    global _prev_err, _prev_time
    enc = read_encoder()
    now = time.time()
    if enc is None:
        return base_speed

    err = enc - desired_ms  # positive if too slow
    p_term = kp * err

    if _prev_err is None:
        d_term = 0.0
    else:
        dt = now - _prev_time
        d_term = kd * ((err - _prev_err) / dt) if dt > 0 else 0.0

    _prev_err, _prev_time = err, now

    thr = base_speed + p_term + d_term # adjust throttle with PD control
    thr = max(throttle_min, min(throttle_max, thr))

    # append for plotting
    err_vals.append(err)
    p_vals.append(p_term)
    d_vals.append(d_term)
    speed_vals.append(thr)

    # print for debugging
    print(f"[manage_speed] enc={enc:.1f}ms err={err:.1f} p={p_term:.3f} d={d_term:.3f} → thr={thr:.3f}")

    return thr

def detect_red_light(frame):
    h, w, _ = frame.shape
    y0 = int(h * 0.95)
    roi = frame[y0:, :] # checks lower part of frame
    hsv = cv2.cvtColor(roi, cv2.COLOR_BGR2HSV)

    # red pixels
    r1 = cv2.inRange(hsv, (0,120,120),   (10,255,255))
    r2 = cv2.inRange(hsv, (160,120,120), (180,255,255))
    mask = cv2.bitwise_or(r1, r2) # combines two red hue ranges
    return cv2.countNonZero(mask)

def detect_edges(frame):
    # Apply hsv for better color contrast, thus better lane detection
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV) # blue for tape lanes
    mask = cv2.inRange(hsv, (90,120,0), (120,255,255))
    return cv2.Canny(mask, 50, 100)

def region_of_interest(edges):
    h, w = edges.shape
    mask = np.zeros_like(edges)
    poly = np.array([[(0, int(h*0.1)), (w, int(h*0.1)), (w,h), (0,h)]], np.int32)

    # try to get the the lane detection near car (not other regions)
    cv2.fillPoly(mask, poly, 255)
    return edges & mask

def detect_line_segments(cropped):
    return cv2.HoughLinesP( # finds straight lines in cropped frame
        cropped, 1, np.pi/180, 10,
        np.array([]), minLineLength=5, maxLineGap=150
    )

def make_points(frame, line):
    h, _, _ = frame.shape
    m, b = line # uses lane's start and end to map lines
    if m == 0: m = 0.1
    y1, y2  = h, h//2
    x1 = int((y1 - b) / m)
    x2 = int((y2 - b) / m)
    return [[x1, y1, x2, y2]]

def average_slope_intercept(frame, segs):
    global prev_left, prev_right

    # if line detection fails (mainly due to camera frame rate)
    if segs is None or len(segs) == 0: # uses previous lines
        lanes = []
        if prev_left is not None:  lanes.append(make_points(frame, prev_left))
        if prev_right is not None: lanes.append(make_points(frame, prev_right))
        return lanes

    h, w, _ = frame.shape
    left_fit = []
    right_fit = []
    boundary = w * (1/3) # divides frame into thirds

    for seg in segs:
        x1, y1, x2, y2 = seg[0]
        if x1 == x2: continue # skip vertical lines
        slope = (y2 - y1) / (x2 - x1)
        intercept = y1 - slope * x1

        if abs(slope) > 0.3 and x1 < boundary and x2 < boundary:
            left_fit.append((slope, intercept))
        elif abs(slope) > 0.3 and x1 > 2*boundary and x2 > 2*boundary:
            right_fit.append((slope, intercept))

    lanes = [] # smooths result using exp moving average
    if left_fit:
        avg_left = np.average(left_fit, axis=0)
        prev_left = avg_left if prev_left is None else ema_alpha*avg_left + (1-ema_alpha)*prev_left
    if right_fit:
        avg_right = np.average(right_fit, axis=0)
        prev_right = avg_right if prev_right is None else ema_alpha*avg_right + (1-ema_alpha)*prev_right
    # averaged slopes and intercepts into line coordinates
    if prev_left is not None:  lanes.append(make_points(frame, prev_left))
    if prev_right is not None: lanes.append(make_points(frame, prev_right))
    return lanes

def display_lines(frame, lanes):
    overlay = np.zeros_like(frame) # draws green line for lanes

    for ln in lanes:
        x1, y1, x2, y2 = ln[0]
        cv2.line(overlay, (x1,y1), (x2,y2), (0,255,0), 6)

    return cv2.addWeighted(frame, 0.8, overlay, 1, 1)

def get_steering_angle(frame, lanes):
    # calculate angle between center of car and canter of lane
    h, w, _ = frame.shape
    if len(lanes) == 2:
        _,_,lx2,_ = lanes[0][0]
        _,_,rx2,_ = lanes[1][0]
        off = ((lx2 + rx2) / 2) - (w / 2) # midpoint of lane
    elif len(lanes) == 1:
        x1, _, x2, _ = lanes[0][0]
        off = x2 - x1
    else:
        off = 0 # no lane detected
    return int(math.degrees(math.atan2(off, h/2))) + 90

def display_heading_line(frame, angle):
    # draws red line showing car direction
    overlay = np.zeros_like(frame)
    h, w, _ = frame.shape
    r = math.radians(angle)
    x1, y1 = w//2, h
    x2 = int(x1 - (h/2)/math.tan(r)) # projects angle up
    y2 = h//2
    cv2.line(overlay, (x1,y1), (x2,y2), (0,0,255), 5)
    return cv2.addWeighted(frame, 0.8, overlay, 1, 1)

def main():
    cap = cv2.VideoCapture(cam_idx)  # set camera idx and frame
    cap.set(cv2.CAP_PROP_FRAME_WIDTH,  frame_w)
    cap.set(cv2.CAP_PROP_FRAME_HEIGHT, frame_h)

    stopped, stop0 = False, 0
    last_s, last_t = 0, time.time()

    try:
        while True:
            ret, frame = cap.read()
            if not ret:
                break # exit if frame not captured
            frame = cv2.flip(frame, 1)

            # stop at red‑light
            red_count = detect_red_light(frame)
            print(f"[red_count] {red_count} (th={RED_THRESHOLD})")
            if red_count > RED_THRESHOLD and not stopped:
                pwm_esc.ChangeDutyCycle(throttle_min)
                time.sleep(3) # first stop
                stopped, stop0 = True, time.time()

            edges = detect_edges(frame) # lane detection
            roi = region_of_interest(edges)
            segs = detect_line_segments(roi)
            lanes = average_slope_intercept(frame, segs)
            angle = get_steering_angle(frame, lanes) # angle calc
            vis = display_heading_line(display_lines(frame, lanes), angle)
            cv2.imshow("heading", vis)

            # throttle control
            thr = manage_speed()
            print(f"[throttle PWM] {thr:.2f}%")
            pwm_esc.ChangeDutyCycle(thr)

            # steering PD
            now = time.time()
            dt  = now - last_t
            e_s = -(angle - 90)
            raw = kp_s * e_s + kd_s * (e_s - last_s) / dt
            raw = max(min(raw, 0.5), -1.0)
            duty = zero_turn + raw * 2.6  # adjust to scale steer sensitivity
            duty = max(servo_min, min(servo_max, duty))
            pwm_serv.ChangeDutyCycle(duty)
            last_s, last_t = e_s, now

            # append steering duty for plotting
            steer_vals.append(duty)

            key = cv2.waitKey(1) & 0xFF
            if key == 27 or key == ord('s'):
                break

    except KeyboardInterrupt:
        print("\nprogram stopped...")

    finally:
        start_frame = 50
        frames = range(start_frame, len(err_vals))

        # plot 1
        fig, ax1 = plt.subplots()
        ax2 = ax1.twinx()
        ax1.plot(frames, steer_vals[start_frame:], label='Steering Duty Cycle')
        ax1.plot(frames, speed_vals[start_frame:], label='Speed Duty Cycle')
        ax2.plot(frames, err_vals[start_frame:],   linestyle='--', label='Error')
        ax1.set_xlabel('Frame Number')
        ax1.set_ylabel('Duty Cycle')
        ax2.set_ylabel('Error')
        lines1, labels1 = ax1.get_legend_handles_labels()
        lines2, labels2 = ax2.get_legend_handles_labels()
        ax1.legend(lines1 + lines2, labels1 + labels2, loc='upper left')
        plt.title('Duty Cycles & Error vs Frame Number (from frame 10)')
        plt.savefig('plt1.png')
        plt.close()

        # plot 2
        fig, ax1 = plt.subplots()
        ax2 = ax1.twinx()
        ax1.plot(frames, p_vals[start_frame:], linestyle='-',  label='Proportional Response')
        ax1.plot(frames, d_vals[start_frame:], linestyle='-.', label='Derivative Response')
        ax2.plot(frames, err_vals[start_frame:], color='gray', linestyle='--', label='Error')
        ax1.set_xlabel('Frame Number')
        ax1.set_ylabel('PD Response')
        ax2.set_ylabel('Error')
        lines1, labels1 = ax1.get_legend_handles_labels()
        lines2, labels2 = ax2.get_legend_handles_labels()
        ax1.legend(lines1 + lines2, labels1 + labels2, loc='upper left')
        plt.title('PD Responses & Error vs Frame Number (from frame 10)')
        plt.savefig('plt2.png')
        plt.close()

        # cleanup
        pwm_esc.ChangeDutyCycle(throttle_min)
        pwm_serv.ChangeDutyCycle(zero_turn)
        cap.release()
        cv2.destroyAllWindows()


if __name__ == "__main__":
    main()
