Node-RED management of YANG model defined devices

The YANG model automated cli parser part of the yangcli tool can now be used from Node-RED.

apt -y install nodejs
apt -y install npm
npm install node-red -g --unsafe-perm
apt -y install libyangrpc-dev libyuma-dev
npm install @lightside-instruments/red-netconf -g --unsafe-perm
node-red

Then you can use the yangcli parser to manage your devices.

Here is export of the flow you can import and get started.

[
    {
        "id": "0a8abee38c7fa043",
        "type": "tab",
        "label": "Flow 1",
        "disabled": false,
        "info": "",
        "env": []
    },
    {
        "id": "39b95a6e4d668c50",
        "type": "netconf session",
        "z": "0a8abee38c7fa043",
        "name": "localhost",
        "host": "127.0.0.1",
        "port": 830,
        "username": "y123",
        "password": "yangrocks",
        "privpath": "",
        "pubpath": "",
        "x": 480,
        "y": 140,
        "wires": [
            [
                "ecca6297b12bda6f"
            ]
        ]
    },
    {
        "id": "0b5f1a68a17123eb",
        "type": "netconf yangcli",
        "z": "0a8abee38c7fa043",
        "name": "yangcli> xget /",
        "sessionNode": "39b95a6e4d668c50",
        "commandTemplate": "xget /",
        "x": 500,
        "y": 380,
        "wires": [
            [
                "ec28385db6b29292"
            ]
        ]
    },
    {
        "id": "ec28385db6b29292",
        "type": "debug",
        "z": "0a8abee38c7fa043",
        "name": "debug 1",
        "active": true,
        "tosidebar": true,
        "console": false,
        "tostatus": false,
        "complete": "false",
        "statusVal": "",
        "statusType": "auto",
        "x": 480,
        "y": 480,
        "wires": []
    },
    {
        "id": "ecca6297b12bda6f",
        "type": "netconf yangcli",
        "z": "0a8abee38c7fa043",
        "name": "yangcli> replace /interfaces/interface[name='wlp2s0']/ipv4 -- mtu=1280",
        "sessionNode": "39b95a6e4d668c50",
        "commandTemplate": "replace /interfaces/interface[name='wlp2s0']/ipv4 -- mtu=1280",
        "x": 670,
        "y": 220,
        "wires": [
            [
                "f5beae121eb66911"
            ]
        ]
    },
    {
        "id": "f5beae121eb66911",
        "type": "netconf yangcli",
        "z": "0a8abee38c7fa043",
        "name": "yangcli> commit",
        "sessionNode": "39b95a6e4d668c50",
        "commandTemplate": "commit",
        "x": 500,
        "y": 300,
        "wires": [
            [
                "0b5f1a68a17123eb"
            ]
        ]
    }
]
