Integration of the RAK12033 Sensor into the Laboratory Monitoring System

Here are the specific elements and tasks to be carried out to integrate the RAK12033 IIM-42652 6-axis accelerometer sensor into the project:

Required Materials and Software (Hardware Addition):

• Sensors (essential for environmental and vibration control):
• 1 x RAK12033 IIM-42652 6-axis Accelerometer (vibration or impact detection on equipment)

Configuration and Implementation Steps (Modifications):

1. Development Environment Preparation

• Install sensor libraries: Add the necessary libraries for the IIM-42652 to your PlatformIO project.

2. Hardware Assembly

• Connect Sensors:
• Connect the RAK12033 (IIM-42652) to an I2C sensor slot.

3. WisBlock Node (RAK4631) Programming

• SensorReading: Write code to read data from the IIM-42652 at regular intervals.
• IIM-42652: Acceleration data on X, Y, Z axes. You can calculate vibration magnitudes or detect impact peaks.
• LoRaWAN Payload: Package the accelerometer data into an efficient LoRaWAN payload format.

5. Cloud IoT Platform Configuration (The Things Stack + Ubidots/Grafana)

• The Things Stack (TTS):
• Configure a "Payload Formatter" (or Decoder) so that TTS can interpret the binary data sent from the node, including the accelerometer data.
• Ubidots / Grafana Cloud / ThingsBoard:
• Create devices/data sources: Configure "devices" or "data sources" on the platform that reflect the accelerometer values (X, Y, Z axes or a calculated magnitude).
• Create Dashboards: Design dashboards with widgets (graphs, gauges, tables) to visualize vibration/impact data in real-time and historically.
• Configure Alerts: Set alert rules (e.g., if vibration exceeds a certain value) to send notifications via email, SMS, or Telegram.

6. Testing and Debugging

• Data Validation: Ensure that the decoded data in TTS and on your visualization platform is correct and makes sense, including the accelerometer data.
• Sensor Testing: Generate vibrations/impacts near the accelerometer to verify that the sensor responds and data updates.
• Alert Testing: Force conditions to trigger vibration/impact alerts and verify that notifications are sent.

Challenges and Troubleshooting Tips (Sensor-Specific Considerations):

• Accelerometer Readings:
• Tip: Accelerometers can be sensitive to noise. Consider using moving averages or filters if readings are erratic. Define clear thresholds for detecting abnormal impacts or vibrations.

Evaluation Criteria (Additions):

• Data Reading: The microcontroller code correctly reads data from the accelerometer.
• Visualization and Dashboard: The dashboard displays accelerometer data.
• Alert System: Alerts for vibration/impact are successfully configured and tested.

✅ 1. Install the library

In PlatformIO (platformio.ini) or Arduino IDE, add:

lib_deps =

RAKWireless/RAK4630-LoRaWan

RAKWireless/IIM42652-Arduino-Library

(If this exact library doesn’t exist, use the official InvenSense library for IIM-42652 or adapt with Wire)

✏ 2. In your code

Include the library:

#include <IIM42652.h>

🧰 3. Declare the sensor instance and variables:

IIM42652 iim; // 6-axis sensor

float accel_x = 0.0, accel_y = 0.0, accel_z = 0.0;

float gyro_x = 0.0, gyro_y = 0.0, gyro_z = 0.0;

⚙ 4. In setup() initialize the sensor:

if (!iim.begin()) {

Serial.println("IIM-42652 not found. Check connections.");

while (1);

}

Serial.println("IIM-42652 initialized successfully.");

📊 5. In the loop() read and print the data:

iim.readSensor();

// Accelerometer

accel_x = iim.getAccelX();

accel_y = iim.getAccelY();

accel_z = iim.getAccelZ();

// Gyroscope

gyro_x = iim.getGyroX();

gyro_y = iim.getGyroY();

gyro_z = iim.getGyroZ();

// Print to serial monitor (for debugging)

Serial.printf("Accel X: %.2f, Y: %.2f, Z: %.2f\n", accel_x, accel_y, accel_z);

Serial.printf("Gyro X: %.2f, Y: %.2f, Z: %.2f\n", gyro_x, gyro_y, gyro_z);

📦 6. Add to LoRaWAN payload

For example, send the Z axis from the accelerometer and gyroscope (to save bytes):

int16_t accZ_int = (int16_t)(accel_z * 1000); // multiply by 1000 to keep 3 decimal places

payload[payload_idx++] = (uint8_t)(accZ_int >> 8);

payload[payload_idx++] = (uint8_t)(accZ_int & 0xFF);

int16_t gyroZ_int = (int16_t)(gyro_z * 1000);

payload[payload_idx++] = (uint8_t)(gyroZ_int >> 8);

payload[payload_idx++] = (uint8_t)(gyroZ_int & 0xFF);

⚠ Make sure to also update your payload decoder on The Things Stack to handle these new fields.

🖼 7. (Optional) Display on OLED screen:

// u8g2.setCursor(0, 60); u8g2.printf("AccZ: %.2f", accel_z);

✅ Quick summary of the workflow:

• Install library → include #include <IIM42652.h>
• In setup(): call iim.begin()
• In loop(): call iim.readSensor() and get values
• Pack values into payload → send over LoRaWAN
