Mocha V 2.0

After I completed a working version of the GoPiGo v2 to work with Windows IoT on Raspberry Pi 3, I started working on the next level of my rover (called Mocha) Sorry I like coffee ;). The samples from Dexter Robotics allowed me to use a Windows 10 UWP project to control the robot with a Panel to make it go forward and backward, left and right. Previous Project Here

No I wanted to not completely blind myself, I added a cheap web camera to the Raspberry Pi.

As the previous project I have the Rover listening to command on one port. With the help of a fellow Hackster Sascha here. I was able to incorporate the HTTP webcam stream to a Panel in Unity by setting up a second Socket Listener.

Now the biggest problem with Unity and streaming of this kind without paying for better asset controls, was to use an old approach. Using a StartCoroutine in Unity for every loop I ask the new stream for a picture. The HTTP webcam streamer will send a single static image back. It is slower than a standard MJpeg web page, but it works in Unity without the need to find a Html Viewer with JavaScript support.

First create a camera object

Camera camera = new Camera();

Then in the loaded event on the MainPage.xaml

           var mediaFrameFormats = await camera.GetMediaFrameFormatsAsync();
           ConfigurationFile.SetSupportedVideoFrameFormats(mediaFrameFormats);
           var videoSetting = await ConfigurationFile.Read(mediaFrameFormats);
           await camera.Initialize(videoSetting);
           camera.Start();
           var httpServer = new HttpServer(camera);
           httpServer.Start();

The starts the HttpServer and sets the camera up. I did make a few adjustments to the quality of image and remarked out the code to allow the MJPEG and control screens from being available.

Now on the Unity side. I created a plane and set a script to handle the image request and display.

public class CameraMaterial : MonoBehaviour {
	public Material frontPlane;
	public Text debugText;
	Plane remoatePlane;
	WebSocket w = null;
	Texture2D tex = null;
	MeshRenderer mr = null;
	int i = 0;
	void Start() {
		tex = new Texture2D (1, 1);
		mr = GetComponent<MeshRenderer> ();
		w = new WebSocket(new Uri("ws://192.168.1.52/videoframe"));
		StartCoroutine (w.Connect ());
		StartCoroutine (StreamPictures ());
	}
	IEnumerator StreamPictures()
	{
		while (true) {
			if (w == null)
				continue;
			byte[] data = w.Recv ();
			if (data != null) {
				tex.LoadImage (data);
				frontPlane.mainTexture = tex;
				mr.material = frontPlane;
				StartCoroutine (WaitForRefresh ());
			}
			w.SendString ("{ \"command\": \"VideoFrame\" }");
			if (w.error != null) {
				Debug.LogError ("Error: " + w.error);
				break;
			}
			yield return 0;
		}
		w.Close();
	}
	IEnumerator WaitForRefresh()
	{
		yield return new WaitForSeconds (0.01f);
	}
}

You will notice the SendString sending a command for a single VideoFrame and that I swap the texture on the Plane with the new image, thus giving the ability to have a somewhat video stream.

Make note that the code can be using in the Unity Editor but make sure to turn the rover upside down so it does not run away.

I welcome any comments on improvements made as this is the end of my rover tutorial. Happy coding!
