Smatrix 1.0 Features-
- Displays Time & Date with icons (16 Preset + Custom icon)
- Alarm
- Stopwatch with animated icon
- Timer with animated icon
- Displays Weather
- Displays Incoming call
- Displays Notifications
- Displays Current playing song (Spotify)
- Displays Youtube subscribers
- Displays Twitter followers
- Displays Instagram followers
- Displays Facebook followers
- MsgBoard with Custom Icon
- Night Light (Automatically Turns On and Off)
- Do Not Disturb
First look of the completed product.
View of the La Matix.
Look at the completed product that you can buy here
If you are adventurous enough, there is also a kit version of the same, that you can buy and do it yourself.
1 / 6 • Power On Animation
Schematic
Arduino Uno and Nano are same so you can use any one of the following boards.
Connections:
Arduino -> Displays:
13 -> CLK
11 -> DATA
10 -> CS
+5 -> VCC
GND -> GND
Arduino -> LDR:
+5 -> 1Pin
A0 -> 2Pin (with 100K resistor to ground) (as shown in fig:LDR)
Arduino -> DS1307:
A4 -> SDA
A5 -> SCL
+5 -> +5v
GND -> GND
Arduino -> Bluetooth:
TX -> RX
RX -> TX
+5 -> VCC
GND -> GND
Arduino -> Buzzer:
8 -> 1Pin
GND -> 2Pin
Arduino -> Switches:
2 -> BtnPWR
3 -> BtnAction not there in the code
4 -> BtnDN not there in the code
Arduino -> NightLIght(Optional):
9 -> +5
GND -> GND
Connections:
Arduino -> Displays:
13 -> CLK
11 -> DATA
10 -> CS
+5 -> VCC
GND -> GND
Arduino -> LDR:
+5 -> 1Pin
A0 -> 2Pin (with 100K resistor to ground) (as shown in fig:LDR)
Arduino -> DS1307:
A4 -> SDA
A5 -> SCL
+5 -> +5v
GND -> GND
Arduino -> Bluetooth:
TX -> RX
RX -> TX
+5 -> VCC
GND -> GND
Arduino -> Buzzer:
8 -> 1Pin
GND -> 2Pin
Arduino -> Switches:
2 -> BtnPWR
3 -> BtnAction not there in the code
4 -> BtnDN not there in the code
Arduino -> NightLIght(Optional):
9 -> +5
GND -> GND
