Published April 25, 2020 © GPL3+

Lappy battery alert and CPU usage

This is the project which gives laptop battery alert via buzzer and also notify heavy cpu usage using LED.

BeginnerFull instructions provided2 days387

Things used in this project

Hardware components

Buzzer

LED (generic)

Jumper wires (generic)

USB-A to Micro-USB Cable

Bolt IoT Bolt WiFi Module

Story

As our day to day life schedule is busy we hardly get time to do minor task or even forgot completely and because of this further we have to face some problem.

One of the problem is our laptop battery monitoring, as we know that our laptop battery are built to handle a certain number of charge cycle and after the cycle's are over we experience discharge of battery very fast. Today's technology is so advance that we have build in feature of battery draining notification but as per our busy schedule sometimes we ignore the notification or also forgot to take action on it. Kindoff sometimes we suffer and find our loss.

Keeping this in mind with the help of BOLT IOT kit I have created a project which monitors the laptop battery and at particular or recommended percent generate alert with the help of Buzzer. Also at same time we also monitor the Laptop CPU utilization. As High utilizatiion affect the performance of system, we have alert system as CPU utilization goes beyond the recommended percent, with help of BOLT IOT LED will glow till the utilization get below the range.

Schematics

Code

Lappy battery alert and CPU usage

import psutil
from boltiot import Bolt
api_key = "def66fbf-e033-403c-a4eb-16fa5bde5bc4"
d_id = "BOLT7422217"

buzzer = Bolt(api_key, d_id)

interval = 3
alert_battery = 20
alert_cpu = 80.0

def control_buzzer(pin, value):
    response = buzzer.digitalWrite(pin, value)

def control_buzzer_frq(pin, value):
    response = buzzer.analogWrite(pin, value)

def control_led(pin, value):
    response = buzzer.digitalWrite(pin, value)

while True:
 cpu_alert = psutil.cpu_percent(interval = interval)
 print ("CPU usage is", cpu_alert)
 if cpu_alert > alert_cpu:
     control_led('1','LOW')
     control_led('2','HIGH')
 else:
     print ("Less utilization")
     control_led('1','LOW')
     control_led('2','LOW')
 battery = psutil.sensors_battery()
 plugged = battery.power_plugged
 percent = str(battery.percent)
 if alert_battery >= int(percent):
     if plugged==False:
         print ("Not Charging alert will generated and Buzzer will sound!!!!")
         control_buzzer('0','HIGH')
     else:
         print ("Charging alert will not generated...")
         control_buzzer('0','LOW')
 else:
     print ("Charging is sufficient")
 battery = psutil.sensors_battery()
 Battery = battery.percent
 if Battery == 100:
     print("Battery Full")
     control_buzzer_frq('0','50')
