Marc AlanizZakariya HashmiIsrael HaileKatherine Han
Published © GPL3+

The Meow Mobile

We converted an RC car into an autonomous vehicle, utilizing a Raspberry Pi 4 and an encoder to provide lane-keeping and speed control.

AdvancedFull instructions provided15 hours318
The Meow Mobile

Things used in this project

Hardware components

Webcam, Logitech® HD Pro
Webcam, Logitech® HD Pro
×1
Optical Speed Encoder
×1
Portable Charger
×1
Raspberry Pi 4 Model B
Raspberry Pi 4 Model B
×1
DC motor (generic)
×1
Servo motor (generic)
×1
RC Car
×1
Cardboard Box
×1

Software apps and online services

OpenCV
OpenCV

Hand tools and fabrication machines

Hot glue gun (generic)
Hot glue gun (generic)
Tape, Clear
Tape, Clear
Scissors, Free Fall
Scissors, Free Fall

Story

Read more

Code

The Meow Mobile's Main Program

Python
The main program that controlled our GPIO pins, used the webcam for computer vision, and kept lane tracking, speed control, and steering control using a PID controller.
# Modules
import cv2
import numpy as np
import math
import time
import os
import RPi.GPIO as GPIO
import matplotlib.pyplot as plt

"""
This code is based on:
User raja_961, “Autonomous Lane-Keeping Car Using Raspberry
Pi and OpenCV”. Instructables. URL:
https://www.instructables.com/Autonomous-Lane-Keeping-Car-U
sing-Raspberry-Pi-and/

Team graDudes, https://www.hackster.io/439751/gradudes-9d9a6e

Team M.E.G.G, https://www.hackster.io/m-e-g-g/the-magnificent-m-e-g-g-car-28ec89
"""

encoder_path = "/sys/module/gpiod_driver/parameters/encoder_val" # To access encoder values from driver
encoder_values = []
max_rotate = 5000000
min_rotate = 8500000
delta = 0.0001
curr_speed = 0

# GPIO setup
GPIO.setmode(GPIO.BCM)
GPIO.setwarnings(False)

# Steering Motor Pins
steering_enable = 19
in1, in2 = 17, 27

# Speed Motor Pins
speed_enable = 18
in3, in4 = 23, 24

# Configure GPIO pins
GPIO.setup(in1, GPIO.OUT)
GPIO.setup(in2, GPIO.OUT)
GPIO.setup(in3, GPIO.OUT)
GPIO.setup(in4, GPIO.OUT)
GPIO.setup(speed_enable, GPIO.OUT)
GPIO.setup(steering_enable, GPIO.OUT)

# Initialize PWMs
gpio_servo_direction = (GPIO.HIGH, GPIO.LOW)
GPIO.output(in1, gpio_servo_direction[0])
GPIO.output(in2, gpio_servo_direction[1])
steering = GPIO.PWM(steering_enable, 50)  # 50Hz for servo
GPIO.output(in3, GPIO.HIGH)
GPIO.output(in4, GPIO.LOW)
speed    = GPIO.PWM(speed_enable, 50)     # 50Hz for motor

NEUTRAL_STEERING = 7.5   # servo neutral duty
FORWARD_SPEED    = 7.4   # motor constant speed duty
STEERING_TRIM    = -0.1  # adjust mechanical bias
Kp = 0.06                # proportional steering gain
Kd = 0.6                 # derivative steering gain ###

# Stop-sign detection state
passed_first   = False
passed_second  = False
red_prev       = False
cooldown       = 30     # frames to ignore after a stop
last_stop_tick = -999   # frame index of last stop

# Start PWMs: steering centered, motor off until move()
steering.start(NEUTRAL_STEERING + STEERING_TRIM)
speed.start(7)  # start stopped
curr_speed = 7

# for stop sign detection
def isRedFloorVisible(frame):

    # Gets color of image
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)

    # Color bounds
    lower1 = np.array([0,10,30], np.uint8) # dark grey
    upper1 = np.array([10,255,255], np.uint8) # light red
    lower2 = np.array([170,10,30], np.uint8) # another gray
    upper2 = np.array([180,255,255], np.uint8) # light blue

    # Masks image (makes 2 seperate then combines)
    mask1 = cv2.inRange(hsv, lower1, upper1)
    mask2 = cv2.inRange(hsv, lower2, upper2)
    mask = cv2.bitwise_or(mask1, mask2) # isolates red and blue

    # Counts percentage of red on the screen after masking
    pct = np.count_nonzero(mask) * 100.0 / mask.size
    return (pct > 10), mask

# image processing
# Masks only the blue part of the image to see lanes
def detect_mask(frame):
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
    lower_blue = np.array([90,50,50]) # lower boundary
    upper_blue = np.array([130,255,255]) # upper boundary
    return cv2.inRange(hsv, lower_blue, upper_blue)

# detects and returns a picture with edges
def detect_edges(mask):
    blur = cv2.GaussianBlur(mask, (5,5), 0)
    return cv2.Canny(blur, 50, 150)

# isolates the image so the pi only looks at lower region of image
# this is to only look at a small portion of the lanes to make it easier
def region_of_interest(edges):
    h, w = edges.shape
    mask = np.zeros_like(edges)
    poly = np.array([[(0,h),(0,h//2),(w,h//2),(w,h)]], np.int32)
    cv2.fillPoly(mask, poly, 255)
    return cv2.bitwise_and(edges, mask)

# Gives line segments that are in the direction of the lanes using the ROI edges picture
def detect_line_segments(roi):
    return cv2.HoughLinesP(roi, rho=1, theta=np.pi/180,
                           threshold=20, minLineLength=20, maxLineGap=15)


# Gets the mathematical formulas (slope and intercept) for the left and right lines
def average_slope_intercept(frame, segments):
    lines = []

    # If there are no segments, just return the lines
    if segments is None:
        return lines

    # Get image height & width, and then find vertical line in middle of image
    # This division is to divide the picture in 2 to seperate left and right of image
    h, w, _ = frame.shape
    mid = w * 0.5

    # This next block of code gets the slope and intercept for each line
    left_fits, right_fits = [], []

    # Iterates through each line segment
    for seg in segments:
        for x1,y1,x2,y2 in seg:
            if x2==x1: continue # if line is vertical, skip
            slope = (y2-y1)/(x2-x1) # calculates slope
            intercept = y1 - slope*x1 # calculates intercept

            # Checks if segment is in left side or right side
            # Puts in respective array afterwards
            if slope<0 and x2<mid:
                left_fits.append((slope, intercept))
            elif slope>0 and x1>mid:
                right_fits.append((slope, intercept))

    # Gets average slope and intercept for each line segment to get an average line
    if left_fits:
        ls, li = np.mean(left_fits, axis=0)
        lines.append([[int((h-li)/ls), h, int((h/2-li)/ls), h//2]]) # Puts left line in final lines array
    if right_fits:
        rs, ri = np.mean(right_fits, axis=0)
        lines.append([[int((h-ri)/rs), h, int((h/2-ri)/rs), h//2]]) # Puts right line in final lines array

    return lines

# Calculates the angle of new trajectory based off the lines
def get_steering_angle(frame, lines):

    # Same thing as last function, divides image into 2
    h, w, _ = frame.shape
    mid_x = w/2

    # Gets center of image
    lookahead = h/2

    #
    if len(lines)==2:
        _,_,l2,_ = lines[0][0]
        _,_,r2,_ = lines[1][0]
        x_offset = ((l2+r2)/2) - mid_x
    elif len(lines)==1:
        x1,_,x2,_ = lines[0][0]
        x_offset = x2 - x1
    else:
        x_offset = 0
    angle = math.degrees(math.atan2(x_offset, lookahead)) + 90
    return angle

# returns how much to adjust the speed by
def manage_speed():

    # Opens encoder using driver and gets value of speed
    f = open(encoder_path, "r")
    encode_val = int(f.readline())
    f.close()

    # Puts in array of speeds
    encoder_values.append(encode_val)
    print("Calculated speed")
    print(encode_val)

    # Logic to change speed based on encoder value
    if encode_val <= max_rotate:
        print("reduce speed")
        ret_val = -delta
    elif encode_val >= min_rotate:
        print("increase speed")
        ret_val = delta
    else:
        print("maintain speed")
        ret_val = 0  # Default if within range

    return ret_val

# Puts lines displayed onto the webcam image on our computer
def display_lines(frame, lines):
    img = np.zeros_like(frame)
    for l in lines:
        x1,y1,x2,y2 = l[0]
        cv2.line(img,(x1,y1),(x2,y2),(0,255,0),4)
    return cv2.addWeighted(frame,0.8,img,1,1)


# Puts the heading line (where the car is supposed to go) on our computer webcam image
def display_heading_line(frame, angle):
    img = np.zeros_like(frame)
    h, w, _ = frame.shape

    # Cool math stuff to calculate heading
    length = h//2
    rad = math.radians(angle-90)
    x1,y1 = w//2, h
    x2 = int(x1 + length*math.sin(rad))
    y2 = int(y1 - length*math.cos(rad))

    # Displays line
    cv2.line(img,(x1,y1),(x2,y2),(0,0,255),4)
    return cv2.addWeighted(frame,0.8,img,1,1)

# Plots p, d and error vs frame number
def plot_pd(p_vals, d_vals, error, show_img=False):
    fig, ax = plt.subplots()
    t = np.arange(len(p_vals))
    ax.plot(t, p_vals, '-', label="P values")
    ax.plot(t, d_vals, '-', label="D values")

    ax.plot(t, error, '--r', label="Error")
    ax.set_xlabel("Frame #") # x axis label
    # y axis labels
    ax.set_ylabel("PD Output")
    ax.set_ylabel("Error (deg)")
    plt.title("PD Control Data")
    fig.legend()
    fig.tight_layout()
    out = os.path.expanduser('~/pd_plot.png')
    try:
        plt.savefig(out) # saves the plot png
        print(f"Saved PD plot to {out}")
    except Exception as e:
        print(f"Error saving PD plot: {e}")
    if show_img:
        plt.show()
    plt.clf()

# Plots motor speed and steering duty vs frame #
def plot_pwm(speed_pwms, turn_pwms, error, show_img=False):
    # Plot the speed steering and the error
    fig, ax1 = plt.subplots()
    t_ax = np.arange(len(speed_pwms))
    ax1.plot(t_ax, speed_pwms, '-', label="Speed")
    ax1.plot(t_ax, turn_pwms, '-', label="Steering")
    ax2 = ax1.twinx()

    ax1.plot(t_ax, error / np.max(error), '--r', label="Error")

    # axis labels
    ax1.set_xlabel("Frames")
    ax1.set_ylabel("Speed and Steer Duty Cycle")
    ax2.set_ylabel("Percent Error Value")

    plt.title("Speed and Steer Duty Cycle, and error v.s. time")
    fig.legend()
    out = os.path.expanduser('~/pwm_plot.png')
    try:
        # saves the pwm plot to current directory
        plt.savefig(out)
        print(f"Saved PWM plot to {out}")
    except Exception as e:
        print(f"Error saving PWM plot: {e}")
    if show_img:
        plt.show()
    plt.clf()


def stop(): # stops motors and re-centers steering
    speed.ChangeDutyCycle(0)
    steering.ChangeDutyCycle(NEUTRAL_STEERING + STEERING_TRIM)


def move(): # starts moving forward at base speed
    speed.ChangeDutyCycle(FORWARD_SPEED)
    steering.ChangeDutyCycle(NEUTRAL_STEERING + STEERING_TRIM)

# main loop
if __name__=='__main__':
    cap = cv2.VideoCapture(0) # opens camera
    cap.set(cv2.CAP_PROP_FRAME_WIDTH,160) # video width
    cap.set(cv2.CAP_PROP_FRAME_HEIGHT,120) # video height

    print("Warming up camera...")
    time.sleep(10) # waits 10s to ensure the camera is ready

    # for PD plotting
    proportional_vals = []
    derivative_vals   = []
    error_vals        = []
    last_error = 0.0
    last_time = time.time()

    # for speed/steering plotting
    speed_pwms = []
    turn_pwms = []

    move() # start driving
    curr_speed = FORWARD_SPEED
    frame_count = 0
    red_prev = False

    while True:
        ret, frame = cap.read() #capture a frame
        if not ret: # breaks if failed to capture
            break

        # checks for red stop sign every 15 frames
        if frame_count % 15 == 0:
            detected, _ = isRedFloorVisible(frame)
            if detected and not red_prev and (frame_count - last_stop_tick > cooldown):
                if not passed_first:
                    stop()
                    time.sleep(4) # wait at 1st stop sign for 4s
                    passed_first=True
                    last_stop_tick=frame_count
                    move() # start moving again
                    curr_speed = FORWARD_SPEED # set speed back
                elif not passed_second:
                    stop() # stop the car permanently
                    passed_second=True
                    break
            red_prev = detected

        # Lane detection
        mask = detect_mask(frame)
        edges = detect_edges(mask)
        roi   = region_of_interest(edges)
        segs  = detect_line_segments(roi)
        lanes = average_slope_intercept(frame, segs)

        # Steering pd calculation
        now  = time.time() ###
        dt = max(now - last_time, 1e3) ###
        angle      = get_steering_angle(frame, lanes)
        error      = angle - 90
        proportional = Kp * error
        derivative   = Kd * (error - last_error) / dt ###

        # log for plotting
        proportional_vals.append(proportional)
        derivative_vals.append(derivative)
        error_vals.append(error)

        # pwm plotting
        speed_pwms.append(curr_speed)

        # Compute and apply steering
        turn = NEUTRAL_STEERING + STEERING_TRIM + proportional + derivative

        # update with speed encoder every 10 ticks
        if frame_count % 10 == 0:
            # adjust speed
            temp_speed = manage_speed() + curr_speed
            # if the change in speed is not 0, update the speed
            if temp_speed != curr_speed:
                speed.ChangeDutyCycle(temp_speed)
                curr_speed = temp_speed

        turn = max(6.0, min(9.0, turn)) # servo limits
        turn_pwms.append(turn)
        steering.ChangeDutyCycle(turn)

        # visualization
        disp = display_lines(frame, lanes)
        disp = display_heading_line(disp, angle)
        cv2.imshow('Lane+Heading', disp)
        if cv2.waitKey(1)==27:
            break
        frame_count += 1 # increment frame

    # After loop ends, save PD plot
    plot_pd(proportional_vals, derivative_vals, error_vals)
    plot_pwm(speed_pwms, turn_pwms, error_vals)

    # Cleanup
    stop()
    steering.stop()
    speed.stop()
    GPIO.cleanup()
    cap.release()
    cv2.destroyAllWindows()

Device Tree Overlay

C/C++
Used to add the encoder and the GPIO encoder pin
/dts-v1/;
/plugin/;

/ {
    fragment@0 {
        target-path = "/";
        __overlay__ {
            encoder {
                compatible    = "a_second_name";
                lights2-gpios = <&gpio 5 0>;
            };
        };
    };
};

Optical Encoder Driver

C/C++
Driver for the optical encoder
#include <linux/module.h>
#include <linux/of_device.h>
#include <linux/kernel.h>
#include <linux/gpio/consumer.h>
#include <linux/platform_device.h>
#include <linux/interrupt.h>
#include <linux/timekeeping.h>
#include <linux/ktime.h>
#include <linux/moduleparam.h>
#include <linux/hrtimer.h>
#include <linux/interrupt.h>
#include <linux/of.h>



/**
* Our module code is based on:
* COMP 424 Project by Team Autonomous Car (Haochen(Jason) Zhang, Ye Zhou, Konstantinos Alexopoulos)
*
* Interrupt code drawn from:
* https://github.com/Johannes4Linux/Linux_Driver_Tutorial/blob/main/11_gpio_irq/gpio_irq.c
**/

// Init variables
unsigned int irq_number; // IRQ num for the GPIO
static struct gpio_desc *my_enc; // gpio descriptor for encoder input
static volatile u64 prev_time; // time of prev interrupt in ns
static volatile u64 curr_time; // time of current interrupt in ns

// time in ns between encoder pulses in ns
static int encoder_val;
module_param(encoder_val, int, 0644);

// Interrupt Handler
static irq_handler_t gpio_irq_handler(unsigned int irq, void *dev_id, struct pt_regs *regs) {

	// Ensure time difference between interrupts is greater than 1 ms
	int enc_val = gpiod_get_value(my_enc);
	curr_time = ktime_get_ns();
	unsigned long elapsed_time = curr_time - prev_time;

    // if rising edge is valid and not within the debounce window
	if (enc_val == 1 && elapsed_time > 1000000) {
		prev_time = curr_time;
        // then store the time difference
		encoder_val = elapsed_time;
		printk(KERN_INFO "irq_handler - timing detected: %lu", elapsed_time);
	}

	return (irq_handler_t) IRQ_HANDLED;
}


// Encoder Probe function
static int enc_probe(struct platform_device *pdev)
{
	//struct gpio_desc *my_btn;
	struct device *dev;
	dev = &pdev->dev;

	printk("enc_probe - RUNNING v5\n");

	// Get GPIO descriptor for the encoder
	my_enc = gpiod_get(dev, "lights2", GPIOD_IN);
	if(IS_ERR(my_enc)) {
		printk("enc_probe - could not gpiod_get_index 0 for btn\n");
		return -1;
	}

	// Set up GPIO interrupt and debounce
	irq_number = gpiod_to_irq(my_enc);
	gpiod_set_debounce(my_enc, 1000000);

    // Request the IRQ
	if(request_irq(irq_number, (irq_handler_t) gpio_irq_handler, IRQF_TRIGGER_RISING, "my_gpio_irq", NULL) != 0){
		printk("Error!\nCan not request interrupt nr.: %d\n", irq_number);
		return -1;	}
	prev_time = ktime_get_ns();
	printk("enc_probe - SUCCESS\n");
	return 0;
}

// Remove function
static void enc_remove(struct platform_device *pdev)
{
	// Free the GPIO descriptor
    free_irq(irq_number, NULL);
	printk("enc_remove - Freed interrupt & Removing\n");
	return;
}

// Device Tree Entry
// Match device tree entries to driver
static struct of_device_id matchy_match[] = {
    { .compatible = "a_second_name", },
	{},
};

// Platform Driver Object
static struct platform_driver my_driver = { // Define the driver
	.probe	 = enc_probe, // Called when the driver is loaded
	.remove	 = enc_remove,  // Called when the driver is unloaded
	.driver	 = {
	       .name  = "The Rock: this name doesn't even matter",
	       .owner = THIS_MODULE,
	       .of_match_table = matchy_match,
	},
};
module_platform_driver(my_driver); // Register the driver

MODULE_ALIAS("platform:my_driver");
MODULE_DESCRIPTION("The Meow Mobile");
MODULE_AUTHOR("Kat, Marc, Israel, Zak");
MODULE_LICENSE("GPL v2");

Credits

Marc Alaniz
1 project • 1 follower
Zakariya Hashmi
1 project • 0 followers
Israel Haile
1 project • 0 followers
Katherine Han
1 project • 0 followers

Comments
