IoT Projects Part 8: Motion Tracking with MPU6050

In this eighth part of our IoT project series, we explore 6-axis motion sensing with ESP32-based MPU6050 integration. This project demonstrates accelerometer and gyroscope data acquisition, JSON-based data transmission, real-time visualization with dual plotting systems, and comprehensive motion analysis capabilities.

Project Overview

This ESP32 project implements a comprehensive motion tracking system with MQTT communication and advanced data visualization. It features an MPU6050 6-axis IMU sensor for precise motion detection, JSON data formatting for structured communication, and real-time monitoring with dual-axis plotting. The Wokwi simulation shows a professional motion sensing setup:

• MPU6050 IMU Sensor: 6-axis motion tracking with 3-axis accelerometer and 3-axis gyroscope
• I2C Communication: SCL (GPIO 22) and SDA (GPIO 21) for digital sensor interface
• Temperature Sensing: Built-in temperature sensor for environmental monitoring
• Power Distribution: 3.3V supply for MPU6050, common ground configuration
• Data Processing: JSON formatting with structured accelerometer, gyroscope, and temperature data

ESP32 Firmware Implementation

The firmware uses a sensor-fusion approach with four core components. Connection Management handles WiFi with retry logic, MQTT with authentication, and automatic reconnection. Sensor Processing provides MPU6050 initialization with I2C communication, 6-axis data acquisition with calibration, and temperature measurement integration. Data Formatting implements JSON structure creation, floating-point precision control, and structured MQTT payload generation. System Activation features MQTT-based enable/disable, status reporting, and configurable update intervals.

MQTT Communication Protocol

The system uses structured MQTT topics for motion data transmission:

• arduino/MPU6050 - JSON-formatted sensor data publishing
• mqtt/request - System activation and status requests
• mqtt/response - Device status and health reports

Message Formats:

Motion Data: {"accelX": 0.12, "accelY": -0.05, "accelZ": 9.81, "gyroX": 1.23, "gyroY": -0.45, "gyroZ": 0.78, "temp": 23.5}
Status Response: "Board : ESP32 Status : Connected"
Status Request: "status_request"
System Control: "TurnOFF"

Key Firmware Features

MPU6050 Sensor Initialization:

#include <Wire.h>
#include <MPU6050.h>

MPU6050 mpu;

void setup() {
    Wire.begin();
    mpu.initialize();

    if (mpu.testConnection()) {
        Serial.println("MPU6050 connection successful");
        mpu.setFullScaleAccelRange(MPU6050_ACCEL_FS_2);
        mpu.setFullScaleGyroRange(MPU6050_GYRO_FS_250);
    } else {
        Serial.println("MPU6050 connection failed");
    }
}

JSON Data Acquisition and Publishing:

void publishSensorData() {
    int16_t ax, ay, az, gx, gy, gz;
    mpu.getMotion6(&ax, &ay, &az, &gx, &gy, &gz);
    int16_t temp = mpu.getTemperature();

    float accelX = ax / 16384.0;  // Convert to g
    float accelY = ay / 16384.0;
    float accelZ = az / 16384.0;
    float gyroX = gx / 131.0;     // Convert to °/sec
    float gyroY = gy / 131.0;
    float gyroZ = gz / 131.0;
    float temperature = temp / 340.0 + 36.53;  // Convert to °C

    String jsonPayload = "{";
    jsonPayload += "\"accelX\":" + String(accelX, 2) + ",";
    jsonPayload += "\"accelY\":" + String(accelY, 2) + ",";
    jsonPayload += "\"accelZ\":" + String(accelZ, 2) + ",";
    jsonPayload += "\"gyroX\":" + String(gyroX, 2) + ",";
    jsonPayload += "\"gyroY\":" + String(gyroY, 2) + ",";
    jsonPayload += "\"gyroZ\":" + String(gyroZ, 2) + ",";
    jsonPayload += "\"temp\":" + String(temperature, 1);
    jsonPayload += "}";

    client.publish("arduino/MPU6050", jsonPayload.c_str());
}

System Activation with Data Rate Control:

void loop() {
    if (systemActive) {
        unsigned long now = millis();
        if (now - lastMsg > 100) {
            lastMsg = now;
            publishSensorData();
        }
    }
}

PyQt5 Dashboard Integration

The dashboard interface provides comprehensive motion monitoring through six main sections:

• MQTT Status Panel - Connection monitoring with LED indicators
• Sensor Data Display - Real-time accelerometer, gyroscope, and temperature values
• Accelerometer Plot - PyQtGraph visualization with X/Y/Z axis curves and legend
• Gyroscope Plot - Separate angular velocity plotting with color-coded axes
• Data Buffering - Circular buffer management with configurable history length
• Error Handling - JSON parsing validation and graceful error state management

Signal-Based Architecture

Signal-slot mechanism for thread-safe updates:

class AccelerometerGyroscopeController(QObject):
    accelerometer_data_changed = pyqtSignal(float, float, float)
    gyroscope_data_changed = pyqtSignal(float, float, float)
    temperature_changed = pyqtSignal(str)
    board_status_changed = pyqtSignal(str, str, str)
    plot_update_signal = pyqtSignal(float, float, float, float, float, float)
    error_state_signal = pyqtSignal()

Thread-Safe Data Processing:

@pyqtSlot(float, float, float)
def update_accelerometer_ui(self, x, y, z):
    if hasattr(self.ui, 'Accelx_lineEdit'):
        self.ui.Accelx_lineEdit.setText(f"{x:.2f} g")
    if hasattr(self.ui, 'Accely_lineEdit'):
        self.ui.Accely_lineEdit.setText(f"{y:.2f} g")
    if hasattr(self.ui, 'Accelz_lineEdit'):
        self.ui.Accelz_lineEdit.setText(f"{z:.2f} g")

@pyqtSlot(float, float, float, float, float, float)
def update_plots_ui(self, accelX, accelY, accelZ, gyroX, gyroY, gyroZ):
    self.accel_data['x'].append(accelX)
    self.accel_data['y'].append(accelY)
    self.accel_data['z'].append(accelZ)

    if len(self.time_data) > self.max_data_points:
        for axis in ['x', 'y', 'z']:
            self.accel_data[axis].pop(0)
            self.gyro_data[axis].pop(0)
        self.time_data.pop(0)

MQTT Message Handling

JSON Data Processing with Error Handling:

def handle_mpu6050_message(self, topic, payload):
    if topic == MQTT_TOPIC_MPU6050:
        try:
            sensor_data = json.loads(payload)

            # Extract data with fallback values
            accelX = sensor_data.get("accelX", 0)
            accelY = sensor_data.get("accelY", 0)
            accelZ = sensor_data.get("accelZ", 0)
            gyroX = sensor_data.get("gyroX", 0)
            gyroY = sensor_data.get("gyroY", 0)
            gyroZ = sensor_data.get("gyroZ", 0)
            temp = sensor_data.get("temp", "--")

            self.accelerometer_data_changed.emit(accelX, accelY, accelZ)
            self.gyroscope_data_changed.emit(gyroX, gyroY, gyroZ)
            self.temperature_changed.emit(str(temp))

            self.plot_update_signal.emit(accelX, accelY, accelZ, gyroX, gyroY, gyroZ)

        except json.JSONDecodeError as e:
            print(f"JSON decode error: {e}")
            self.error_state_signal.emit()

Status Monitoring with Message Filtering:

def handle_status_response_message(self, topic, payload):
    try:
        if payload.strip() == "status_request":
            return  # Ignore our own status requests

        if "Board :" in payload and "Status :" in payload:
            board_part, status_part = payload.split("Status :")
            board_name = board_part.replace("Board :", "").strip()
            status = status_part.strip().lower()

            if status == "connected":
                self.board_status_changed.emit(board_name, "Connected", "green")
                self.led_status_changed.emit("green")
                self.status_received = True
    except Exception as e:
        print(f"Error processing status message: {e}")

Control Flow Analysis

Motion Data Flow:

• Sensor Reading: MPU6050 provides 6-axis motion data plus temperature via I2C
• Unit Conversion: Raw ADC values converted to meaningful units (g, °/sec, °C)
• JSON Formatting: Structured data packet creation with floating-point precision
• MQTT Publishing: JSON payload transmitted to arduino/MPU6050 topic at 10Hz
• Dashboard Processing: JSON parsing, validation, and real-time UI updates

Visualization Flow:

• Data Reception: JSON payload received and parsed by dashboard
• Buffer Management: New data appended to circular buffers with length control
• Plot Updates: PyQtGraph curves updated with latest data points
• Auto-Scaling: Dynamic range adjustment for optimal visualization
• Legend Management: Color-coded axis identification with professional appearance

Advanced Features

Dual-Plot Visualization System:

def init_plots(self):
    self.accel_plot.setBackground(QColor(0, 0, 0, 100))
    self.accel_plot.setTitle("Accelerometer Data (g)", color='w', size='14pt', bold=True)
    self.accel_plot.addLegend()
    self.accel_plot.showGrid(x=True, y=True)

    self.accel_x_curve = self.accel_plot.plot(pen='r', name="AccelX")
    self.accel_y_curve = self.accel_plot.plot(pen='g', name="AccelY")
    self.accel_z_curve = self.accel_plot.plot(pen='b', name="AccelZ")

    self.gyro_plot.setTitle("Gyroscope Data (°/sec)", color='w', size='14pt', bold=True)

Circular Buffer Data Management:

def __init__(self, mqtt_client, ui):
    self.accel_data = {'x': [], 'y': [], 'z': []}
    self.gyro_data = {'x': [], 'y': [], 'z': []}
    self.time_data = []
    self.max_data_points = 100  # Configurable history length

Error State Management:

@pyqtSlot()
def show_error_state_ui(self):
    error_text = "ERR"
    if hasattr(self.ui, 'Accelx_lineEdit'):
        self.ui.Accelx_lineEdit.setText(error_text)
    for field in ['Accelx_lineEdit', 'Accely_lineEdit', 'Accelz_lineEdit',
                  'Gyrox_lineEdit', 'Gyroy_lineEdit', 'Gyroz_lineEdit', 'temp_lineEdit']:
        if hasattr(self.ui, field):
            getattr(self.ui, field).setText(error_text)

Comprehensive System Deactivation:

def deactivate(self):
    self.mqtt_client.publish(MQTT_TOPIC_MQTT_Rq, "TurnOFF")

    self.accel_data = {'x': [], 'y': [], 'z': []}
    self.gyro_data = {'x': [], 'y': [], 'z': []}
    self.time_data = []

    if hasattr(self, 'accel_plot'):
        self.accel_plot.clear()
        self.accel_plot.setTitle("Accelerometer Data (g)")
        self.accel_plot.showGrid(x=True, y=True)

    self.mqtt_client.unsubscribe_from_topic(MQTT_TOPIC_MPU6050)
    self.mqtt_client.unsubscribe_from_topic(MQTT_TOPIC_MQTT_Rs)

Conclusion

This ESP32 motion tracking system demonstrates advanced 6-axis sensor integration with structured JSON communication, dual-axis real-time visualization, and comprehensive motion analysis capabilities. The system provides professional-grade motion sensing with accelerometer and gyroscope data fusion, temperature monitoring, and sophisticated dashboard visualization.

In the next part of this series, IoT Projects Part 9: ESP32 Gas Detection and Safety Monitoring, we'll explore environmental safety sensing with MQ-series gas sensors, threshold-based alerting, and automated safety response systems.
