Created May 18, 2020

Providing Sensor Data using Industry Marketplace

Industries provide Sensor Data to Companies through Industry Marketplace

Story

Whenever fire accidents take place, they cause great harm and destruction and sometimes loss of property. Thus, the factories usually take fire insurance policies to compensate for the loss. And if the factory claims for false insurance then also the insurance company compensates for the loss, so by buying the sensor data from these plants insurance companies can save themselves from false claims

In this example we have a Steel manufacturing plant called "HardSteel", which provides sensor data like temperature and pressure values to companies like insurance companies like "InsureLife" in this example through Industry Marketplace.

Required softwares for getting started with Industry Marketplace are as follows:

Node.js

We will use NVM for installing Node.js. NVM (Node Version Manager) is a bash script used to manage multiple active Node.js versions. With NVM you can install and uninstall any specific Node.js version you want to use or test.

First we will install NVM, to download and install the nvm script run:

curl -o- https://raw.githubusercontent.com/nvm-sh/nvm/v0.35.3/install.sh | bash

The command above will clone the NVM repository from Github to the ~/.nvm directory:

=> Close and reopen your terminal to start using nvm or run the following to use it now:

export NVM_DIR="$HOME/.nvm"
[ -s "$NVM_DIR/nvm.sh" ] && \. "$NVM_DIR/nvm.sh"  # This loads nvm
[ -s "$NVM_DIR/bash_completion" ] && \. "$NVM_DIR/bash_completion"  # This loads nvm bash_completion

As the output above says, you should either close and reopen the terminal or run the commands to add the path to nvm script to the current shell session. You can do whatever is easier for you.

Once the script is in your PATH, verify that nvm was properly installed by typing:

nvm --version
0.35.3

Now that the nvm is installed we can install the latest available version of Node.js, by typing:

nvm install node

Once the installation is completed, verify it by printing the Node.js version:

node --version
v14.2.0

To list installed Node.js versions type:

nvm ls

The output should look something like this:

->      v14.2.0
         system
default -> node (-> v14.2.0)
node -> stable (-> v14.2.0) (default)
stable -> 14.2 (-> v14.2.0) (default)
iojs -> N/A (default)
unstable -> N/A (default)
lts/* -> lts/erbium (-> N/A)
lts/argon -> v4.9.1 (-> N/A)
lts/boron -> v6.17.1 (-> N/A)
lts/carbon -> v8.17.0 (-> N/A)
lts/dubnium -> v10.20.1 (-> N/A)
lts/erbium -> v12.16.3 (-> N/A)

The entry with an arrow on the right (-> v14.2.0) is the Node.js version used in the current shell session and the default version also v14.2.0. Default version is the version that will be active when opening new shells.

For deploying Industry Marketplace, we will be using v12.16.3. As there are some problems in using v14.2.0 with Industry Marketplace. Also note the for running the Service App Node.js v10 or higher is required. Therefore we will use v12.16.3

For installing v12.16.3 type

nvm install v12.16.3

After the installation is complete we will be making v12.16.3 as the default Node.js version. For changing the default Node.js version to 12.16.3, use the following command

nvm alias default 10.16.3

Yarn

Yarn is a new package manager that replaces the existing workflow for the npm client or other package managers while remaining compatible with the npm registry. It has the same feature set as existing workflows while operating faster, more securely, and more reliably.

curl -sS https://dl.yarnpkg.com/debian/pubkey.gpg | sudo apt-key add -
echo "deb https://dl.yarnpkg.com/debian/ stable main" | sudo tee /etc/apt/sources.list.d/yarn.list

Since we have used nvm we will avoid the installation of node, by typing

sudo apt update && sudo apt install --no-install-recommends yarn

Note : Due to the use of nodejs instead of node name in some distros, yarn might complain about node not being installed. A workaround for this is to add an alias in your .bashrc file, like so: alias node=nodejs . This will point yarn to whatever version of node you decide to use.

Running the Industry Marketplace

Cloning the Industry Marketplace for provider

git clone --depth=1 https://github.com/iotaledger/industry-marketplace.git provider

Cloning the Industry Marketplace for requester

git clone --depth=1 https://github.com/iotaledger/industry-marketplace.git requester

Cloning the python-helper function for using the Industry Marketplace as a Sensor Data Marketplace:

git clone https://github.com/iota-community/industry-marketplace-python-helper.git python-helper

We will be running both the requester and provider nodes on the same machine, so we will change the ports of provider from 4000 to 4001. This is done using the different ports patch file in python-helper folder

So, firstly change the directory to provider/

$ cd provider/

Then apply the different port patch

$ git apply ../python-helper/patches/different_ports.patch

Also we will be using the comnet node as the devnet is no longer used by the IOTA community. So we will also apply a patch for changing the nodes from devnet to comnet.

$ git apply ../python-helper/patches/comnet.patch

Also apply this patch in the requester folder

$ cd ../requester
$ git apply ../python-helper/patches/comnet.patch

After doing all this we are ready to launch the ServiceApp

Launching the ServiceApp:

Currently we are in the requester folder, so we will first lauch the requester app:

$ cd ServiceApp
$ yarn run dev

After running this command for the first time, it will take some time in downloading the dependencies and deploying them

Open a new Terminal and navigate to the ServiceApp of the requester folder

$ cd requester/ServiceApp
$ yarn run dev

Once the development server is ready, terminal will look something like this

and on a new browser window Industry Marketplace will start and will look something like this

Our requester node is ready, now do the same ie launching the server for provider also

Once both the requester and provider are ready goto the python -helper folder

$ cd ../../python-helper

make a virtual environment for python

$ python3 -mvenv ../env
$ . ../env/bin/activate
$ pip install -r requirements.txt

and run

$ python service_provider

on a new terminal window, type the following commands

$ . ../env/bin/activate
$ python service_requester

Voila!!

Everything is setup and ready to test.

from imp import IndustryMarketplace
import random
import pprint

class ServiceProvider(IndustryMarketplace):
    name = 'HardSteel'
    service_provider = True
    fund_wallet = False
    gps_coords = '54.123, 4.321'

    endpoint = 'http://localhost:4001'

    def on_cfp(self, data, irdi, submodels):
        '''
        As soon as this service provider receives a CfP this function is called
        You can use the supplied irdi and submodels to define a price if you like
        '''

        self.log('Call for Proposal received for irdi %s!' % irdi)
        #self.log('Submodels: ')
        #pprint.pprint(submodels)

        if irdi == '0173-1#01-BAF888#004':
            price = 50
        else:
            self.log('We only provide Sensor Data, ignore this one!')
            return

        try:
            ret = self.proposal(data, price_in_iota=price)
        except Exception as e:
            self.log('Unable to send proposal', e)

        self.log('proposal sent! Requesting %si for this service' % price)

    def on_accept_proposal(self, data, irdi, submodels):
        self.log('Proposal accepted! Start fulfilling')
        self.log('Sending inform confirm')
        ret = self.inform_confirm(data)
        #self.log(ret)

    def on_reject_proposal(self, data, irdi, submodels):
        self.log('Proposal rejected! Either do nothing or offer a Discount?')
        #pprint.pprint(data)

    def on_inform_payment(self, data, irdi, submodels):
        self.log('Payment received! IMP transaction done!')
        #pprint.pprint(data)


if __name__ == '__main__':
    imp = ServiceProvider()
    imp.listen()

from imp import IndustryMarketplace
import pprint
import sys

class ServiceRequester(IndustryMarketplace):
    name = 'InsureLife'
    service_provider = False
    fund_wallet = True
    gps_coords = '54.000, 4.000'

    endpoint = 'http://localhost:4000'

    def on_proposal(self, data, irdi, submodels):

        self.log('on proposal called!')
        try:
            price = self.get_price(irdi, submodels)
            self.log('Received proposal for %si for irdi %s' % (price, irdi))
            if not price:
                self.log('Price not found, submodels: %s' % submodels)

            if price >= 5 and price <= 15:
                self.log('Accepting proposal')
                self.accept_proposal(data)
            else:
                self.log('Rejecting proposal')
                self.reject_proposal(data)
        except Exception as e:
            self.log('Error on accepting: %s' % e)

    def on_inform_confirm(self, data, irdi, submodels):
        self.log('Offer confirmed, time to pay')
        self.inform_payment(data)


if __name__ == '__main__':

    imp = ServiceRequester()

Credits

Utkarsh Verma

3 projects • 3 followers

I'm an Electronics Engineering Undergraduate and I like to create projects in Embedded Systems, Internet of Things and Machine Learning.
